All our products are custom-made, so there is no standard pricing. Please get in touch with us for details based on your specific needs.
| Fujian Fangda Electronic Weighbridge General Parameter Table
Version-SCS,Sensor-C3/C6,Steel material：Q235B | |||
| Display Mode | LED | Protection Grade | IP68 |
| Weighing Method | Static weighing | structure | U-shaped steel |
| operational environment | Non-explosion-proof type | Lightning Protection Design | With lightning protection |
| power | AC220/Hz50 | Delivery Time | Within 15-30days |
| Weighing Range | 30ton-80ton | Panel thickness | 8mm~14mm |
| Transport Packaging | Load with 20-foot or 40-foot standard containers | Certification Description | SCS, ISO9001: 2005 |
| brand | Fangda | Production Capacity | 1000 Sets/Sets Per Year |
| HS Code | 8423891090 | Source | Zhang Zhou, Fujian, China |
| Custom Size： | 2.5*5m,2.5*6m,3*5m,3*12m,3*16m,3*18m,3*24m，and others, which can be customized according to actual needs. | ||
FAQ:
A: Yes. Fujian Fangda’s 80-ton truck scales are specifically engineered to thrive in harsh mining environments. Equipped with IP68-rated load cells, they are fully sealed to effectively block dust and water intrusion. Additionally, the U-beam steel structure is coated with a high-durability anti-corrosion finish, enabling it to withstand extreme temperature fluctuations commonly encountered in African mining areas.
A: Our 80-ton truck scales comply with both JJG 539 and OIML R76 standards, and hold an Accuracy Class III certification. This level of precision ensures reliable and compliant bulk trade settlement for mining, logistics, and related industrial operations.
Overview
Features:
- 1: Industrial weighing system equipped with anti-tampering features, enabling unattended operation.
- 2: The SCS series of truck scales has an accuracy class of C3/C6 and is OIML-certified.
- 3: National accuracy class III, with a verification scale interval of 3000–6000.
- 4: Standard platform widths are 2.5 m and 3 m, with customization available upon request; standard platform lengths range from 5 m to 20 m, and can be customized based on vehicle models.
- 5: Maximum permissible error: 0–500 e: ±0.5 e; 500 e–2000 e: ±1.0 e; 2000 e–maximum capacity: ±2.0 e.
- 6: Sensor accuracy class: C3; total error ≤ 0.02% FS
- 7: Operating temperature (indicator): -10°C to 40°C;
- 8: Sensor: -30°C to 70°C; relative humidity ≤ 90% RH, no condensation
- 9: Protection rating (sensor): IP67/IP68;
- 10: Instrument: IP65
- 11: Power requirements: AC 187 V–242 V, 50 Hz
- 12: Safe overload: 125% FS; Maximum overload: 300% FS
